₨1,535
| Colour | White |
| Conductor | AWG 24 – 22 |
| Jack Type | RJ45 – 8/8 |
| Housing material | Plastic |
| Insulation diameter max. | 1.6mm |
| Number of Stranded Wires | 7 |
| RoHS | Free of hazardous substances according to RoHS 2011/65/EU |
| Approvals and Listings | ISO/ IEC 11801 Edition 2, Am 1-2,IEC 60603-7-41, EN 50173-1,ANSI/ TIA/ EIA-568-C.2-2009, – IEC 60512-99-001 |
| Design And Test Criteria | IEEE 802.3 10GBASE-T, IEEE 802.3at |
| Depth | 34 mm |
| Width | 18 mm |
| Height | 23 mm |
| Category | 6A |
| Tool-less jack | Easy and quick to install – reliable connection The conductors are wired in a single operation |
| Integral shutter | No additional shuttering required on faceplates |
| Hardware Performance | Can be mixed and matched with other Hardware certified copper cable and patchcords |
| Three cable entry points | Less cable bending required – better compliance with minimum bend radius |
| Accepts solid and stranded conductors | Enables “jack-to-plug” cables to be manufactured using stranded conductors |
| No untwisting of pairs before termination | Minimized stripping length – limited pair untwist – pairs kept together, no wire guide required |
| Insulation resistance | > 500 MΩ |
| Lead Through Resistance | < 200 mΩ |
| Voltage Rating (Maximum) | <75 |
| Contact surface | Gold, 1.27 µm |
| Reproducibility | Several times reusable |
| Solid Wire Diameter | 5mm to 65mm |
Our Cat.6A copper interconnect products work together to provide an easy-to-use solution for deploying high-speed connections throughout a building. The RJ45 jack is a key component in this system. These RJ45 jacks have been certified by an independent test laboratory to hardware certification. Each jack component is able to terminate to any certified Cat.6A cable and patch cord combination to achieve full channel performance. The jack’s unique three cable entry points help make installation simple. The traditional one-click design enables an easy, tool-less termination on unshielded twisted pair cables, meeting industry performance standards.
